PCB Prototyping Machine

Shenzen Xinaoxun Co., LTD has more than 10 years of extensive experience in providing worldwide customers with one-stop PCB manufacturing solutions.

product detail

Founded in 2015, Xinaoxun is a professional PCB board company which focus on high precision and high quality single-sided and double-sided and multi- layer and AL boards and high frequency and many other boards.

According to the circuit board layer can be divided into single panel, double panel, four layer board, 6 layer board and other multilayer circuit board.

product description

Files	Gerber, protel, powerpcb, autocad, orcad, etc
Material	Tg FR4, Lead free Materials (RoHS Compliant)
Layer No.	1 – 28 Layers
Copper thickness	0.5OZ – 4OZ
Board Thickness	Tolerance(-10%~10%)
Impedance Control	-10%~10%
Warpage	0.075%-1.5%
Peelable	0.012″(0.3mm)-0.02′(0.5mm)
Min Trace Width (a)	0.005″(0.125mm)
Min Space Width (b)	0.005″(0.125mm)
SMD Pitch (a)	0.012″(0.3mm)
Register tolerance	0.05mm
Min Solder Mask Dam (a)	0.005″(0.125mm)
Soldermask Clearance (b)	0.005″(0.125mm)
Min SMT Pad spacing (c)	0.004″(0.1mm)
Solder Mask Thickness	0.0007″(0.018mm)
Hole size	0.01″(0.25mm)– 0.257″(6.5mm)
Hole Size Tol (+/-)	-0.003″~0.003”(-0.0762mm~0.076mm)
Aspect Ratio	06:01
Hole Registration	0.004″(0.1mm)
HASL	2.5um
Lead free HASL	2.5um
Immersion Gold	Nickel 3-7um Au:1-3u”
OSP	0.2-0.5um
Panel Outline Tol (+/-)	-0.004”~0.004”(-0.1mm~0.1mm)
Beveling	30 45
V-cut	15 30 45 60
Surface finish	HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink
Certificate	ROHS, ISO9001:2000

Purchase Tips:

1. For PCB order, please provide SinoFast file or PCB file. Any detail is also welcomed without the file.

2. Large PCB quantity order, quotation will be based on SQM.

3. For PCBA order, please provide the Gerber file, pcb file and BOM List.

4. Reverse engineering and PCB clone service can be supplied with your PCB sample.

5. Any question, welcome to contact our sales person by sending inquiries.
